Optional
Optinonal standard rail or heavy duty rail
| Model | SA-350 | SA-450 |
| Basic size/PCB | Max350mm | Max450mm |
| Transfer speed | 400 -1800mm/min | 400 -1800mm/min |
| Preheater power | 21.6KW | 21.6KW |
| Tin furnace power | 18KW | 18KW |
| Transmission motor | 1ΦAC220V 90W | 1ΦPAC220V 90W |
| Cooling fan | 1ΦAC220V 370W | 1ΦAC220V 370W |
| Tin wave motor | 2-3ΦAC22OV 370W | 2-3ΦPAC220V 370W |
| Cleaning motor | 1ΦPAC220V 30W | 1ΦPAC220V 30W |
| Tin furnace temperature | Room temperature ~ 300°C | Room temperature ~ 300°C |
| Tin furnace capacity | 480kg | 520kg |
| Solder angle | 5.5°±1.0° adjustable | 5.5° ±1.0° adjustable |
| Gas source | >4kg/ cm2 | >4kg/ cm2 |
| Automatic addition of flux | Standard configuration | Standard configuration |
| Normal/Starting power | 12kw/29.5kw | 13kw/36.5kw |
| Net weight | 1650kg | 1800kg |
| Dimensions(mm) | 4250(L)×1580(W)×1650(H) | 4250(L)×1580(W)×1650(H) |
| Power supply | 3Φ380V | 3Φ380V |
