Technical Parameters
| Description | Automatic board operation for light boards |
| Time for feed PCBs | Approx.6 seconds or specified by customer |
| Board maximum capacity | 200pcs(0.6mm thick PCB) |
| Power supply and electric load | 220V(AC,SP) 150VAmax |
| Air pressure | 4~6bar, Up to30 L/min |
| Thickness of PCBs | 0.6~4.0mm |
Specifications & Parameters
| Model | Dimensions(mm) | Circuit board effective size(mm) | Weight(kg) |
| DL-460 | 600(L)×990(W)×1200(H) | 50(L)×50(W)-500(L)×550(W) | 130(kg) |
| DL-550 | 750(L)×1000(W)×1200(H) | 50(L)×50(W)-700(L)×550(W) | 180(kg) |
