Technical Parameters
| Description | For light board automatic closing operation |
| Time for feed PCBs | Approx.6 seconds or specified by customer |
| Board maximum capacity | 200pcs(0.6mm thick PCB) |
| Power supply and electric load | 220V(AC,SP)150VA max |
| Air pressure | 4~6bar,Up to30L/min |
| Thickness of PCBs | 1.0~4.0mm |
Specifications & Parameters
| Mode | Dimensions(mm) | Circuit board effective size(mm) | Weight(kg) |
| DZ-460 | 600(L)×975(W)×1200(H) | 50(L)×50(W)-500(L)×550(W) | 130(kg) |
| DZ-550 | 730(L)×975(W)×1200(H) | 50(L)×50(W)-700(L)×550(W) | 180(kg) |
