High-speed Magazine Unloader (Model: ZL-MSOP8)
| 一、Equipment Features： | ||
| 1 | The unloading device of the circuit board of the SMT production line | |
| 2 | PLC control, color man-machine interface operation | |
| 3 | The stepper motor pushes the plate structure, and the push plate strength and speed can be adjusted | |
| 4 | Servo lifting system, accurate positioning, fast lifting speed, and high production efficiency | |
| 5 | Multiple electrical distribution circuit protection, safe and reliable | |
| 6 | Sound and light prompt alarm system, abnormal information text prompt, easy operation and maintenance | |
| 7 | Standard SMEMA signal communication mode | |
| 二、Main specifications and Technical parameters | ||
| 1 | Description | It is used for the automatic feeding of circuit boards to the production line |
| 2 | Number of bins | Upper tracks 2; Lower tracks 2 |
| 3 | Container replacement time | Approx. 25 seconds or user-specified |
| 4 | Power supply and electrical load | 220V AC, single-phase max. 300 VA |
| 5 | Voltage and airflow | 4~6 bar, up to 0.1 l/min |
| 6 | Board thickness | Minimum 0.8 mm |
| 7 | Lift motor | Servo motor |
| 8 | Push plate motor | Blue stepping |
| 9 | Clamp frame cylinder | Taiwan Airtac |
| 10 | Lifting screws | TBI |
| 11 | Inductor | Lawne |
| 12 | Operational type | Kunlun Tongtai |
| 13 | Control mode | Panasonic PLC of Japan |
| 14 | Conveying direction | Left to right, right to left (optional) |
| 15 | Transmission height | 900±20mm |
| 16 | The effective size of PCB (length * width) | 100*50mm ~260*100mm |
| 17 | Transmission height | 900±20mm |
| 18 | Dimensions (L*W*H) | 890*1020*1600mm |
| 19 | Container size (L*W*H) | 260*58*144mm |
| 20 | Approximate weight (kg) | Approx. 150kg |
| 21 | Docking AGV height | The upper and lower magazine track ground clearance: 812, 534mm |
| 22 | Remark | You can set the number of starting layers, the number of output PCBs, and the PCB spacing parameters |
