Technical Parameters
| Description | Used to automatically send circuit boards to the production line |
| Time for feed PCBs | Approx.6 seconds or specified by customer |
| Power supply and electric load | 220V(AC,SP)800VAmax |
| Thickness of PBCs | 0.6mm min |
Specifications &Parameters
| Model | ML-500 | ML-800 |
| Circuit board effective size(mm) | 60(L)×60(W)-400(L)×300(W) | 60(L)×60(W)-510(L)×460(W) |
| Transmission height(mm) | 900±20(mm) | 900±20(mm) |
| Dimensions(mm) | 500(L)×650(W)×1500(H) | 850(L)×850(W)×1565(H) |
| Layer spacing of product(mm) | 10(mm) | 10(mm) |
| Maximum number of boards | 48 | 48 |
| Weight(kg) | 80(kg) | 110(kg) |
