Technical Parameters
Description | Used to automatically send circuit boards to the production line |
Time for feed PCBs | Approx.8 seconds or specified by customer |
Board maximum capacity | 200pcs(0.6mm thick PCB) |
Power supply and electric load | 220V(AC,SP)120VAmax |
Air pressure and air flow | 4~6bar,Up to30 L/min |
Thickness of PCBs | 0.6mm min |
Specifications & Parameters
Model | ZK-450X-750 | ZK-750X-1000 |
Circuit board effective size(mm) | 510(L)×460(W) | 700(L)×550(W) |
Transmission height(mm) | 900±20(mm) | 900±20(mm) |
Dimensions(mm) | 750(L)×1500(W)×1750(H) | 900(L)×1610(W)×1750(H) |
Weight(kg) | 500(kg) | 600(kg) |
